1000 KW GENERATOR NATURAL GAS POWERED FOR SALE – CJV# 1775

1000 kW generator.
Two distinct options.

1000 kW Generator Natural Gas Package at a Glance

Ready for prime or stand-by power, this Waukesha L7042GL powered package makes 1 MW / 1000 kW of power with only 34,000 hours on overhauled components. The engine has been preserved, features a 62 kW black start generator and an air compressor system for a complete facility. It’s currently disconnected in a yard beside highway #22, which is high load corridor for easier logistics. Additionally, this 1000 kW generator package is a perfect candidate for a conversion to multi-stage pump, see below!

Prime Power Turnkey Solution: 1000 kW Generator Business Case

As an alternative to buying this generator as is, we’ve prepared and can execute a full turnkey cost saving power generation solution. Below is a cost comparison at a glance.

Current Energy Costs

Post-installation Operating Costs

Estimated Total Annual Savings

Contact us to see the full business case document and project costing for this option of a 1000 kW generator turnkey solution.

1000 KW GENERATOR LISTING QUICK LINKS

You know people we don’t – that information is valuable!

The owner of this 1000 kW generator has included a large cash sales incentive for bringing a buyer. Even if you aren’t a broker/reseller, if you have information which leads to a sale, you will be compensated. Contact us to learn more about this exciting opportunity.

Components of the 1000 kW Generator Propak Package

Waukesha L7024GL

  • VHP, 12 cylinder
  • Rated 1472 HP – 1097 kW @ 1200 RPM
  • Rated Continuous Service
  • Fuel – Natural Gas

Propak Fin Tube Aerial Cooler Assembly

  • Jacket water section
  • After-cooler section
  • Belt Driven Fan from Engine

KATO 1000 kW Generator Assembly

  • 6P6-1900 1000Kw/1250 KVA
  • 277/480/3/60 VAC
  • 1504 Amps
  • Rated Continuous Service

Thompson MEC-20 Micro Controller Panel

  • Synchronous Generator/Engine Controller
  • Woodward Governor Control
  • Main Breaker
  • Engine Monitoring Annunciator

Kohler 60 kW Black Start Unit

  • Engine – John Deere 4045TF150C
  • Fuel – Diesel
  • Generator – Kohler 60REQZI
  • 62 kW
  • 277/480/3/60 Vac
  • 71 Amps

Eagle Instrument Air Compressor

  • Qty. 2 screw compressors
  • Qty. 2 TECO 20 HP, 480/3/60 VAC motors
  • 100 Gallon Storage tank
  • Automated air dryer assembly

Building & Skid

  • Length 40’
  • Width 20’
  • Height 22’
  • Weight 100,000 lbs.
  • Qty. 4 Lifting lugs on each side of the skid/building assembly.

Additional Cooler Dimensions

  • Width 20’
  • Length 10’
  • Height 12’

A 1400 hp Pump Package for $600k?

“But this is a 1000 kW generator?!?” you may be asking… This building, due to its size and setup, is a PERFECT candidate for converting to an engine driven water injection pump package. We recently completed a 7042 conversion to pump for a client who was paying unbelievable power costs. Click here to learn about that project.

In short, order a pump, overhaul the engine, order a gearbox, build your piping out complete with charge pump, filters, bypass, metering etc. and then complete it with an Allen Bradley PLC/HMI (program included). In addition, we’ll spend a couple days on site doing the start-up and commissioning of it.

You will be HALF the price of buying new, and be pumping in 10 weeks… FROM TODAY!

1000 kW Generator Photo Gallery

1000 kW Generator Price & Quick Facts

As Is Price: $215,000

Condition

Field Ready and/or Minor Repair

Manufactured

PROPAK 2001

Location

Rocky Mountain House, AB

Status

Disconnected

Availability

Immediate

kW Rating

1000 kW Generator

Driver

Waukesha L7042GL 1472HP

Generator

Kato Engineering 1000kW Generator, 1250kVA, 60Hz, 3PH, 1200RPM, Continuous Duty, 277/480 Volts, 1504 Amps

Controllers

Thompson Technology Engine Controller m/n:MEC20; 4-20mA engine mounted Woodward governor

Cooler

PROPAK

Dimensions

40’ L x 20’ W x 15’6” eave H

1 MW / 1000 kW Generator Feature Sheet

Download this 1000 kW generator’s details as a PDF – with the option of an unbranded version to share with your network.

Highlights for 1 MW / 1000 Generator Redeployment

Whether you’re going to redeploy this 1000 kW generator in its original configuration, with minor adjustments or alternatively convert it to a multi-stage pump package with our help – we have the knowledge and expertise to get this package producing for your needs.

Engine – Engine has 34,000 hours on it since major overhaul. It requires a head swing and turbos. The full scope of work can be completed in one week prior to leaving yard with detailed pricing available on request. Engine has been preserved.

    Electrical – The panel & complete electrical system has received a detailed inspection and scope of work required by DJA Electrical Services. Unit electrical requires $2700 worth of parts to be 100% operational and current.

      Inquiries

      Call us at 403-819-3906 or fill out the form below to discuss this 1000 kW generator.

      •
